Product Details:
Payment & Shipping Terms:
|
| Fork Length: | 1200mm | Min. Lifting Height:: | 2660 |
|---|---|---|---|
| Max.lift Height(mm): | 6000mm | Loading Capacity: | 6000kg |
| Rated Loading Capacity: | 3 Ton 5 Ton | Travel Speed: | 29 Km Per Hour |
| Highlight: | road construction vehicles,construction paver machine |
||
Low Price 5 Ton Side Loader Lading Forklift Truck , Diesel Engine Side Load Fork Lift For Wood Pipe Long Goods Transport
1, This side loader forklift allows you to transport heavy and long good in a small place ,
2, it can transport good such as long wood , pallet , pipe , other building material and industrial goods without make a turn.
3, it saves rooms and alow you to use it instead of making it as a transportation path .
4, This side loader forklift use Japanese Technology Hydraulic system with ISUZU ENGINE.
| CONFIGURATION DIMENSIONS AND PWRFORMANCE | BL50 | BL60 | |
| Rated Capacity | kg | 5000 | 6000 |
| CG of cargo | mm | 600 | 600 |
| Max. lift height | mm | 3600 | 3600 |
| Max. lift speed(laden) | mm/s | 350 | 350 |
| Max. traveling speed(laden) | Km/s | 24 | 24 |
| Fork tilt angle(up/down) | Deg | 3/5 | 3/5 |
| Gradeability | % | 20 | 20 |
| Platform width | mm | 1300 | 1300 |
| Platform lngth | mm | 5150 | 5150 |
| Fork length | mm | 1220 | 1220 |
| Axle spacing | mm | 2800 | 2800 |
| Wheel spacing Front of the wheel spacing | mm | 1750 | 1750 |
| Wheel spacing Behind of the wheel spacing | mm | 1750 | 1750 |
| Overall dimension(LXWXH) | mm | 5150X2100X2800 | 5150X2100X2800 |
| Weight unladen | kg | 8000 | 8500 |
| Tyre size Front wheel | mm | 2-9.00-16-14PR | 2-9.00-16-14PR |
| Tyre size Hindrear wheel | mm | 2-9.00-16-14PR | 2-9.00-16-14PR |
| Engine | |||
| Manufacturer | ISUZU | ISUZU | |
| Model | 6BG1 | 6BG1 | |
| Rated powet/Speed | kw | 82.3/2000 | 82.3/2000 |
