| Operating Weight: | 6.5 T | Bucket Capacity: | 0.3m3 |
|---|---|---|---|
| Maximum Digging: | 5800mm | Maximum Digging Depth: | 3380mm |
| Rated Speed: | 2400r/min | Rated Power: | 65KW |
| High Light: | 6.5 Ton Wheel Excavator,Log Grapple Wheel Excavator |
||
2020 hot sale 1.8 Ton Mini Crawler Excavator with Automatic Transmission
1,Field installation, commissioning and training, Field mainte
2,PLC, Pressure vessel, Engine, Gear, Motor, Pump, Bearing,
3,This mini crawler excavator specifically designed for use off-track cutting ballast, is a revolutionary system
designed to undercut track without wasting valuable track time. scoops out contaminated gravel and
mud and fouled ballast from beneath railroad tracks.
| RANGE OF OPERATION | Boom Length | 3475~3670mm | ||||||||
| Arm Length | 1860mm | |||||||||
| Max Radius Of Capture | 6000mm | |||||||||
| Grab The Biggest Opening Width | 1250~1500mm | |||||||||
| Grab The Minimum Opening Width | 200~300mm | |||||||||
| Maximum Radius Weight Capacity | 0.5~0.6t | |||||||||
| Grapple Rotation Angle | 360° | |||||||||
| Max Dumping Height | 4700mm | |||||||||
| Back-End Radius Of Gyration | 1775mm | |||||||||
| DIMENSION | (Length*Width*Height) Travel Position | 6000*2100*2850mm | ||||||||
| Wheel Base | 2600mm | |||||||||
| Track(Front/Rear) | 1660mm/1580mm | |||||||||
| Ground Clearance Of Counterweight | 1060mm | |||||||||
| Min Ground Clearance | 200mm | |||||||||
| TECHNICAL PARAMETERS | Angle Of Rotation | 360° | ||||||||
| Machine Weight | 6500kg | |||||||||
| Engine Model | YN38GB2/4100 | |||||||||
| Rated Power | 58.8kw | |||||||||
| Rated Speed | 2200r/min | |||||||||
| Hydraulic System Working Pressure | 19.5Mpa | |||||||||
| Hydraulic system flow | 110L/min | |||||||||
| Metering gear pump | 2*25ml/r | |||||||||
| Grapple Swing Speed | 15~30r/min | |||||||||
| Walking Speed | 36km/h | |||||||||
| Grade Climbing Ability | 58%/30° | |||||||||
| Tyre model | 825.16 | |||||||||
| Revolution overdrive pressure | 16Mpa | |||||||||
| Full Circle Swinging Time | 5.5s | |||||||||
| Fqt Fuel Quantity | ≥4L/h | |||||||||
| Capacity Of The Fuel Tank | 130L | |||||||||
| Hydraulic Tank Capacity | 110L | |||||||||
