| Type: | Skid Steer Loader | Machine Weight: | 1100kg |
|---|---|---|---|
| Certification: | CE,GOST,EPA | Engine: | Chinese Weichai Brand |
| Rated Power: | 100hp | Bucket Capacity: | 0.55m3 |
| High Light: | Mini Skid Steer Loader,100HP Skid Steer Loader,0.55m3 Skid Steer Loader |
||
Wholesale 100HP Mini Skid Steer Loader With Chinese weichai brand diesel engine WP4.1
| Item | Description | Item | description |
| Rated operating capacity(kg) | 1100 | Hinge pin height (mm) | 3150 |
| Tipping load (kg) | 2200 | Total height (mm) | 2160 |
| Bucket capacity(m3) | 0.55 | Length with bucket (mm) | 3580 |
| Hydraulic pump flow (L/min) | 80/140 | Length without bucket(mm) | 2880 |
| Engine power (hp) | 100 | Width with bucket (mm) | 1880 |
| Weight(kg) | 3550 | Track width (mm) | 1500 |
| Max travel speed (km/h) | 12 | Wheelbase (mm) | 1115 |
| Grade ability | 20 | Ground clearance (mm) | 205 |
| Tire | 12-16.5 | Dumping angle | 40 |
| Fuel/hyd oil capacity (L) | 90/90 | Dumping height (mm) | 2450 |
| Height at maximum extension | 4070 | Maximum reach (mm) | 700 |
