Product Details:
Payment & Shipping Terms:
|
| Frequency: | 50/60HZ | Cylinder No.: | 6 |
|---|---|---|---|
| Rated Speed: | 1500rpm | Rated Power: | 80 Kw/100 KVA |
| Size: | 3000*1240*1800mm | Excitation Mode: | AC Rotating Exciter |
| High Light: | 30kVA Diesel Generator Set,50kVA Diesel Generator Set |
||
1. Genset
1) Prime Power: 24KW/30KVA
2) Standby power: 30KW/37.5KVA
3) Frequency: 50Hz
4) Speed: 1500rpm
5) Phases: Three phases, four wires
| Engine Data | Engine Brand | RICARDO | |||
| Engine model | R6105AZLDS | ||||
| Standby output power/speed | 121KW/1500RPM | ||||
| Cycle | four | ||||
| Number of cylinders | 6 in line | ||||
| Bore×Stroke | 105×130mm | ||||
| Displacement | 6.75L | ||||
| Fuel consumption rate(100%) | 20.2L/Hr | ||||
| Fuel consumption rate(75%) | 17.8L/Hr | ||||
| Aspiration | Turbocharged | ||||
| Compression ratio | 16:1 | ||||
| Lubricating capacity | 17L | ||||
| Cooling method | Water cooled | ||||
| Speed governor | Mechanical governor | ||||
| Starting model | 24V Electric | ||||
| Fuel injection mode | Direct injection | ||||
| Alternator Data | Alternator Brand | (COPY STAMFORD) | |||
| Alternator model | YKW-80 | ||||
| Rated power | 80KW/100KVA | ||||
| Phase | Three phase four wire | ||||
| Power factor | 0.8 | ||||
| Voltage | 400/230V | ||||
| Exciter type | Self -excited, brushless pure copper, AC synchronous, single bearing | ||||
| Insulation grade | H | ||||
| Protection grade | IP23 | ||||
| Voltage regulator | Standard AVR | ||||
