Product Details:
Payment & Shipping Terms:
|
| Horsepower: | 251 - 350hp | Tank Volume: | 10001 - 15000L |
|---|---|---|---|
| Engine Capacity: | 9.726L | Drive Wheel: | 6x4 |
| Dimensions (L X W X H) (mm): | 10350x2496x3048 Mm | Water Tank Capacity: | 15 M3 |
| High Light: | water bowser truck,sanitation dump truck |
||
251 - 350HP Shacman 6x4 15000 Liters Water Tank Truck for sale
15000 Liters Water Truck Tanks 251 - 350HP Shacman 6x4 For Fire Fighting Function
1). Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction.
2). Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform.
3). The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30M.
4). Equipped with fire coupling, flow valves, filter screen and water level gauge.
5). According to customers’ request, the crane, high working platform and spraying machine also can be equipped.
6). Mainly used for washing on urban roads, watering and greening on trees, green belts and lawn and dust full of construction sites. And also used for drinking water delivery and fire fighting function etc.
| Product | 6*4 water tanker truck | ||
| Chassis model | SHACMAN F2000 | ||
| Chassis | Overall dimensions | mm | 9719*2500*3400 |
| parameters | Gross weight | kg | 25000 |
| Kerb weight | 11500 | ||
| Rated payload | |||
| Suspension F/R | mm | 1525/2519 | |
| Wheel base | 4325+1350 | ||
| Drive type | 6*4 | ||
| Number of axles | 3 | ||
| Number of Spring leafs | 43750 | ||
| Gearbox | FAST 9JS135 | ||
| Steering system | power steering | ||
| Tire specification | 12.00-20 | ||
| Number of Tires | 10+1 | ||
| Allowable passengers in cab | 3 | ||
| Engine | Engine model | WD615.50 | |
| Type of fuel | Diesel | ||
| Displacement/power | ml/hp | 9726/280 | |
| Max speed | Km/h | 92 | |
| Emission standard(TAS) | EURO 2 | ||
| Tank | 1. Effective cubage: 20 cbm | ||
| 2.Thickness of the tank: 4mm | |||
| 3. Material Q235 carbon steel |
