Product Details:
Payment & Shipping Terms:
|
| Engine Capacity: | 9726ml | Gross Vehicle Weight: | 16000 |
|---|---|---|---|
| Drive Wheel: | 4x2 | Dimensions (L X W X H) (mm): | 9397x2500x3290 |
| Volume: | 16m3 | Time Of Discharging: | ≤45s |
| Highlight: | water bowser truck,sanitation dump truck |
||
Sinotruk Brand New 10 Ton 16 m3 Compactor Garbage Truck
1. Sinotruk howo professional garbage truck.
2. HW70 cabin,no sleeper, with air--conditioner
3. HW70 cabin, right hand drive, no sleeper with A/C
4. 295/80R22.5, tubeless radial 6+1 spare tire
| Chassis Model | HOWO ZZ1167M4611W |
| Overall Dimensions(L×W×H)(mm) | 9315x2500x3215 |
| Pressure of Hydraulic System(MPa) | 20 |
| Kerb Mass (kg) | 12150 |
| Loading Mass (kg) | 3720 |
| Gross Vehicle Weight (kg) | 16000 |
| Max. Speed(kg/h) | 90 |
| Cabin | HW70 cabin, right hand drive, no sleeper with A/C |
| Engine Model | WD615.62 266hp |
| Engine Output(HP/r/min) | 266HP@2100rpm |
| Gearbox | HW13710+HW70 PTO, 10 speeds |
| Front axle | HF7, 7T disc brake |
| Rear axle | ST16, 16T loading capacity, ratio=4.42 |
| Steering | Power steering |
| Tire |
295/80R22.5, tubeless radial 6+1 spare tire |
| Body Volume(m3) | 16 |
| Filler Volume( m3) | 2.0 |
| Cycle Time of Filling(s) | ≤25 |
| Lifting Time of Filler(s) | 8-10 |
| Time of Discharging(s) | ≤55 |
| Front / Rear Sewage Tank volume(L) | 250+150 |
| Rated pressure of hydraulic system(Mpa) | 20 |
| Mechanical hand(standard) | 240L |
